Equine Cushing’s and Insulin Resistance Group Inc.

Physiology of
Equine Metabolic Syndrome (EMS)

In horses, there's little doubt that high-carbohydrate feeding influences the response to insulin, but it's more complicated than in people or other animals. The horse evolved without any sources of concentrated carbohydrate in its diet.

Insulin Resistance (IR) in ponies was reported almost 40 years ago. IR in horses was recognized less than 15 years ago. However, a 1989 USDA-sponsored survey found that 13% of the owners and equine premises surveyed reported having laminitis problems in the prior 12 months. Laminitis was second only to colic as a reason for seeking veterinary care. We now know that 90+% of all laminitis cases are caused by high blood insulin. Prior to IR and Equine Metabolic Syndrome (EMS) coming into the limelight as the "disease du jour", it was very common for breeders involved with susceptible breeds to vehemently deny they had any laminitis problems or that there was a genetic link — but insiders knew otherwise.

With insulin resistance, circulating levels of insulin are elevated but glucose stays normal. The cells are resistant to insulin's signal to take up glucose, but higher levels get the job done. Horses do not progress to be frankly diabetic as easily as other species do. Diabetes mellitus is when blood sugar is higher than normal.

Glucose is the most important, and the most precious, fuel in the body. Every cell needs it, even the ones that can depend heavily on fat as an energy source. The capacity to store glucose in the tissues is low. To compensate for this, many pathways exist for converting other nutrients into glucose if need be. Many amino acids can be converted to glucose.

The energy crisis that results when insulin does not stimulate normal uptake of glucose by insulin-sensitive cells is at least part of the reason for higher levels of circulating cholesterol and lipids in IR. Fats are released in an effort to provide calories to cells that are getting inadequate energy. At the same time, high levels of insulin tend to shut down the burning of fuels in muscle and fat, channeling them instead into storage forms. Glycogen goes down because glucose entry is impaired, but at the same time the burning of fuels is inhibited so more fat gets stored — a vicious circle.

Blue. PPID. IR. Iron Overload.

How AMP factors in Insulin Resistance

AMP, or activated protein kinase (AMPK), is discussed on the Physiology of PPID page and it is more than worth repeating and expanding this information here since it is a key factor in the metabolic upheaval of insulin resistance. ATP is adenosine triphosphate, a major chemical source of energy in all cells. ATP holds phosphate energy bonds that are "transferred" and used for work, including muscular exercise, when the phosphorus is released. When the cell needs energy, a phosphate group is split off the ATP molecule to generate energy, changing ATP into ADP and AMP. At this point, the cell's bank of energy stores is getting to a critical level. When functioning normally, ADP is rapidly converted back to ATP and AMP levels are low. This cycling goes back and forth between ADP and ATP constantly within the cells. If energy demand is high, some ADP will be further broken down to AMP. As AMP levels rise, alarm bells go off and it's AMPK enzyme to the rescue.

When AMPK is activated by rising AMP levels, it triggers the following effects:

  1. Increased glucose uptake by the cell
  2. Increased burning (oxidation) of fats
  3. Production of GLUT4 glucose transporters (the insulin-sensitive ones)
  4. Mobilization of GLUT4 glucose transporters (does not require insulin during exercise)
  5. Manufacture of more mitochondria (the "factories" or "ovens" in the cell where glucose and fat are burned)

AMPK is also active in the liver where it:

  1. Suppresses production and release of lipoproteins
  2. Suppresses production and release of cholesterol

Some other interesting facts about AMPK are that they are:

  1. Stimulated by the adipokines leptin and adiponectin
  2. Stimulated by thyroid hormone

Decreasing the effects of AMPK in muscle and liver gives you all the metabolic consequences of insulin resistance

AMP activated protein kinase:
a next generation target for total metabolic control 1

Misra P., Discovery Research, Dr Reddy's Hyderabad, India. parimal@drreddys.com

Metabolic syndrome is characterized by a cluster of metabolic disorders, such as reduced glucose tolerance, hyperinsulinemia, hypertension, visceral obesity and lipid disorders. The benefit of exercise in maintaining total metabolic control is well known and recent research indicates that AMP-activated protein kinase (AMPK) may play an important role in exercise-related effects. AMPK is considered as a master switch in regulating glucose and lipid metabolism. AMPK is an enzyme that works as a fuel gauge, being activated in conditions of high phosphate depletion. In the liver, activation of AMPK results in decreased production of plasma glucose, cholesterol, triglyceride and enhanced fatty acid oxidation. AMPK is also robustly activated by skeletal muscle contraction and myocardial ischemia, and is involved in the stimulation of glucose transport and fatty acid oxidation by these stimuli. In adipose tissue, activated AMPK inhibits deposition of fat, but enhances breakdown and burning of stored fat, resulting in reduction of body weight. The two leading diabetic drugs, namely metformin and rosiglitazone, and adipokines, such as adiponectin and leptin, show their metabolic effects partially through AMPK. These data suggest that AMPK may be a key player in the development of new treatments for obesity, Type 2 diabetes and the metabolic syndrome.


We know that insulin resistance is associated with leptin resistance and low levels of circulating adiponectin. This could explain lowered activity of AMPK. The ability of thyroid hormone to stimulate AMPK activity may be behind the beneficial effect of thyroid supplementation in horses with IR, especially in horses that are showing low thyroid function. The popular human drug, Metformin, works by stimulating AMPK, although it certainly isn't a cure, and diet and exercise remain the most successful way to treat IR in people as well as horses.

Metformin was tried in horses in one small US study. It didn't work.2   However, a larger field study in the UK found significant improvement in insulin resistance in 18 chronically laminitic horses and ponies studied on the drug for as long as 220 days.3   The most dramatic improvements were seen in the first two weeks, with insulins beginning to rise again after that time but remaining better than at the start of the study. In terms of their laminitis, owners reported 78% had improved, while 22% were unchanged or worse. No side effects were reported. A concern with Metformin is excessive lowering of blood glucose, since horses do not seem to have overproduction of glucose the way human patients do. However, this study found that although there is a transient drop in blood glucose shortly after Metformin is given, the degree was mild. Metformin is not the magic bullet for IR. Response decreases over time and in some horses it does not work at all. However, it can be a useful tool for gaining rapid control of IR in horses that are in crisis.

Further evidence of defective activity of AMPK in insulin resistance is that uric acid levels are elevated. This has been well described in people but was largely ignored in horses except for one pony study in the UK. This interesting study below also found that IR ponies were hypertensive, yet another similarity with human metabolic syndrome:

Frosty EMS

Hypertension and insulin resistance in a mixed-breed population of ponies predisposed to laminitis4

Bailey SR, Habershon-Butcher JL, Ransom KJ, Elliott J, Menzies-Gow NJ. Department of Veterinary Basic Sciences, Royal Veterinary College, Royal College Street, London, NW1 0TU, England.

OBJECTIVE:
To determine the metabolic phenotype of a group of laminitis-prone ponies when at pasture in summer, compared with when at pasture in winter. ANIMALS: 40 ponies of various breeds predisposed to recurrent pasture-associated laminitis and 40 unaffected control ponies.
PROCEDURES:
Body condition score and size of the crest of the neck were assessed, blood samples obtained, and blood pressure measured by use of an indirect oscillometric technique, while ponies were kept on winter pasture (last week of November or beginning of December) and again on summer pasture (June). Serum insulin concentration and plasma glucose, triglyceride, uric acid, and ACTH concentrations were measured. Insulin sensitivity was calculated with proxies derived from basal serum insulin and plasma glucose concentrations.
RESULTS:
No significant differences were apparent between ponies predisposed to laminitis and control ponies during winter. However, in June, laminitis-prone ponies had increased serum insulin concentration and plasma triglyceride and uric acid concentrations, compared with control ponies. Also, laminitis-prone ponies were relatively insulin resistant, compared with control ponies. Mean blood pressure was significantly higher during summer in laminitis-prone ponies (median [interquartile range], 89.6 mm Hg [78.3 to 96.9 mm Hg]), compared with control ponies (76.8 mm Hg [69.4 to 85.2 mm Hg]).
CONCLUSIONS AND CLINICAL RELEVANCE:
Summer pastures appear to induce metabolic responses in some ponies, leading to expression of the prelaminitic phenotype, which includes hypertension as well as insulin resistance. Signs of this metabolic syndrome may not be apparent in affected ponies during periods of grazing winter pasture. Understanding this syndrome may enable improved countermeasures to be devised to prevent laminitis.

If you have heard of uric acid at all, it was probably in connection with gout, but this isn't gout. Uric acid is a breakdown product of purines. High uric acid in insulin resistance is coming from failure to recycle AMP back to ADP and ATP. When AMP cannot be reloaded with phosphate groups because of insufficient or inefficient use of nutrients to replenish ATP, the AMP is broken down by a process which creates inosine from the adenosine purine in AMP.

Why isn't AMP being cycled back into ADP and ATP?

Because failure to maximally activate the enzyme AMPK means energy-generating pathways that would normally replenish ATP are not being signaled properly and glucose is not being taken up normally. [Note: Uric acid is also elevated after strenuous, and especially exhaustive, exercise.]

With all the biochemical changes in insulin resistance pointing a finger directly at the AMPK enzyme, it does indeed make perfect sense to look toward AMPK activation as a therapy. The simplest way to rev up AMPK is also one of the most successful ways to alleviate insulin resistance — EXERCISE.


Information Contained On This Page Adapted From
Equine Cushing's & Insulin Resistance Course
Offered by Eleanor M. Kellon, VMD www.drkellon.com



Misral P, AMP Activated Protein Kinase: A Next Generation Target for Total Metabolic Control, Expert Opin Ther Targets, 2008 Jan;12(1):91-100. doi: 10.1517/14728222.12.1.91.

Vick MM, Sessions DR, Murphy BA, Kennedy EL, Reedy SE, Fitzgerald BP, Obesity is associated with altered metabolic and reproductive activity in the mare: effects of metformin on insulin sensitivity and reproductive cyclicity. Reprod Fertil Dev. 2006 ;18(6):609-17. doi: 10.1071/rd06016. PMID: 16930507.

Durham AE, Rendle DI, Newton JR, The effect of metformin on measurements of insulin sensitivity and β cell response in 18 horses and ponies with insulin resistance. Equine Veterinary Journal, 2008 Jul;40(5):493-500. doi: 10.2746/042516408X273648.

Bailey SR, Habershon-Butcher JL, Ransom KJ, Elliott J, Menzies-Gow, NJ, Hypertension and Insulin Resistance in a Mixed-Breed Population of Ponies Predisposed to Laminitis. Am J Vet Res 2008 Jan;69(1):122-9. doi: 10.2460/ajvr.69.1.122.
